DuPont AmberLite HPR650 H Cation Exchange Resin with Sulfonic Acid Functional Groups and Styrene-Divinylbenzene Matrix for Mixed Bed Applications
商品の詳細:
| 起源の場所: | 中国 |
| ブランド名: | Dupont |
| 証明: | ISO9001 |
| モデル番号: | Dupont™Amberlite™HPR650 H |
| ドキュメント: | IER-AmberLite-HPR650-H-PDS-...en.pdf |
お支払配送条件:
| 最小注文数量: | 1pc |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | 標準輸出梱包 |
| 受渡し時間: | 5-8勤務日 |
| 支払条件: | T/T |
| 供給の能力: | 月額60000ユニット |
|
詳細情報 |
|||
| HPR650 H コポリマー: | スチレンジビニルベンゼン | HPR650 H マトリックス: | ゲル |
|---|---|---|---|
| HPR650 Hタイプ: | 強酸カチオン | HPR650 H官能基: | 硫酸 |
| HPR650 H 保水力: | 46.0 - 52.0％（h⁺form） | HPR650 H イオン変換: | H⁺≥99％ |
| HPR650H 用途: | 電力産業向けの混合ベッド脱灰のアプリケーション | ||
| ハイライト: | HPR650 H Cation Exchange Resin,Sulfonic Acid Functional Groups Ion Exchange Resin,Styrene-Divinylbenzene Matrix AmberLite HPR650 H |
||
製品の説明
Designed for use in mixed-bed applications for condensate polishing in both nuclear (PWR) and fossil power plants, as well as for industrial water demineralization.
AmberLite™ HPR650 H is a high-quality, high-capacity cation exchange resin. It is a strong acid cation exchange gel resin with sulfonic acid functional groups and a styrene-divinylbenzene matrix.
This resin is known for its uniform particle size, excellent mechanical strength, and oxidative stability, making it ideal for high-flowrate applications. Formerly marketed as Dowex Monosphere 650C, it complies with FDA regulation 21 CFR 173.25 for use as a food additive.
- Recommended Pairings:
- AmberLite™ HPR550 OH Ion Exchange Resin (gel)
- AmberLite™ HPR9000 OH Ion Exchange Resin (macroporous)
- Additional Options:
- AmberLite™ HPR550 Cl Ion Exchange Resin (gel)
- AmberLite™ HPR9000 SO₄ Ion Exchange Resin (macroporous)
- Mixed bed condensate polishing in PWR nuclear power plants
- Mixed bed condensate polishing in fossil fuel power plants
- Mixed bed polishing in industrial demineralization systems
AmberLite™ HPR650 H Ion Exchange Resin was previously sold as DOWEX MONOSPHERE™ 650C (H) Ion Exchange Resin.
| Physical Properties | |
|---|---|
| Copolymer | Styrene-divinylbenzene |
| Matrix | Gel |
| Type | Strong acid cation |
| Functional Group | Sulfonic acid |
| Physical Form | Dark amber, translucent, spherical beads |
| Chemical Properties | |
|---|---|
| Ionic Form as Shipped | H⁺ |
| Total Exchange Capacity | ≥ 2.0 eq/L (H⁺ form) |
| Water Retention Capacity | 46.0 - 52.0% (H⁺ form) |
| Ionic Conversion | H⁺ ≥ 99% |
| Particle Size | |
|---|---|
| Particle Diameter | 650 ± 50 μm |
| Uniformity Coefficient | ≤ 1.10 |
| < 300 μm | ≤ 0.5% |
| > 850 μm | ≤ 5.0% |
| Purity (dry basis) | |
|---|---|
| Metals: |
|
| Stability | |
|---|---|
| Whole Uncracked Beads | ≥ 95% |
| Friability: |
|
| Swelling (Na⁺ -> H⁺) | 7% |
| Density | |
|---|---|
| Particle Density | 1.22 g/mL |
| Shipping Weight | 785 g/L |
For additional particle size information, please refer to the Particle Size Distribution Cross Reference Chart (Form No. 45-D00954-en).
Temperature Range (H⁺ form): 5 - 150°C (41 - 302°F)
pH Range (Stable): 0 - 14
For further details regarding recommended minimum bed depth, operating conditions, and regeneration procedures for mixed beds (Form No. 45-D01127-en) or separate beds (Form No. 45-D01131-en) in water treatment, please refer to our Technical Facts documents.
