Veolia E-Cell MK-3 Mini HT EDI module for pharmaceutical ultrapure water production
商品の詳細:
| 起源の場所: | 中国 |
| ブランド名: | VEOLIA |
| 証明: | CE |
| モデル番号: | Veolia Edi Mk-3miniht |
| ドキュメント: | FSpwE-CellMK-3MiniHT_EN.pdf |
お支払配送条件:
| 最小注文数量: | 1 PC |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | 標準輸出梱包 |
| 受渡し時間: | 1か月 |
| 支払条件: | T/T |
| 供給の能力: | 月額60000ユニット |
|
詳細情報 |
|||
| ミニフローレート範囲: | 0.5–1.6 m3 /h（2.2–7.0 gpm） | Miniht製品の配送重量: | 57 kg（126ポンド） |
|---|---|---|---|
| このモデルのminiht寸法（幅x高さx深さ）: | 30 cm x 61 cm x 29 cm | miniht抵抗率: | ≥10（医薬品）または≥16moM-cm（産業 |
| 製品ナトリウム: | ≤3ppb（産業） | 製品の最大消毒温度: | 85ºC（185ºF） |
| 製品の最大消毒吸気圧力: | 2.1バー（30 psi） | 製品の用途: | USPおよびEPに準拠した医薬品および実験室の精製水 |
| ハイライト: | Veolia E-Cell MK-3 EDI module,pharmaceutical ultrapure water EDI,mini HT EDI module |
||
製品の説明
The Veolia E-Cell MK-3 Mini HT Electrodeionization (EDI) Module is designed for polishing reverse osmosis (RO) permeate to produce ultra-pure water. It delivers high-purity water (up to 10 MΩ·cm resistivity, with ≤5 ppb silica) without chemical regeneration. Ideal for power generation, semiconductors, microelectronics, and pharmaceuticals, this compact module (30x61x28 cm) offers continuous operation, high recovery rates (78-93%), and hot water sanitization capabilities
| Flow Rate Range | 0.5–1.6 m³/h (2.2–7.0 gpm) |
| Shipping Weight | 57 kg (126 lbs) |
| Dimensions | 30 cm x 61 cm x 29 cm |
| Resistivity | ≥ 10 MOhm-cm (Pharmaceutical) or ≥ 16 MOhm-cm (Industrial) |
| Maximum Sanitization Temperature | 85ºC (185ºF) |
- Patented HT-EDI™ technology for reagent-grade water production
- 90% lower energy consumption compared to mixed-bed systems
- Maintenance-free operation with intelligent control system
- Real-time monitoring of conductivity, pH, and pressure drop
- Patented staggered flow channel design prevents scaling
Maintains resistivity above 18.2 MΩ*cm with 22% energy reduction compared to traditional EDI equipment. Achieves recovery rates exceeding 90% even with high-hardness raw water.
- Basic Unit - Standalone purification
- RO-EDI Integrated - Complete purification skid
- GMP Version - With full validation support
- CE, RoHS, CSA and EAC marked
- FDA-compliant materials
- UKCA certified
- Manufactured in ISO 9001 and ISO 14001 facility
- Halal certified by IFANCA®
| Parameter | Value |
|---|---|
| Inlet Pressure | 6.9 bar (100 psi) |
| Max Temperature | 40°C (104°F) |
| Pressure Drop | 1.4-2.8 bar (20-40 psi) |
| Recovery Rate | Up to 93% |
| Conductivity | <117 µS/cm |
| pH Range | 4-11 |
Ideal for water for injection, pharmaceutical purified water, and laboratory purified water systems. Complies with USP, EP, and other pharmacopeia standards.
