詳細情報 |
|||
| 30Z-5最小流量M3/HR（GPM）: | 1.70（7.5） | 30Z-5設計流量m3/hr（gpm）: | 3.3-5.11（15.0-22.5） |
|---|---|---|---|
| 30Z-5出荷重量kg（lbs）**: | 132（291） | 30Z-5動作重量kg（lbs）: | 110（243） |
| 30Z-5回復: | 90〜95％ | 30Z-5の利点: | 高純度水 |
| スタック温度: | 5–45℃（41〜113°F） | スタック入口圧力: | 1.4–6.9バー（20–100 PSIG） |
| 応用: | 産業用 | ハイライト: | 化学物質のないEDIモジュール、高純度の水CEDIモジュール、産業用イオンプアLX-Zモジュール |
製品の説明
The Ionpure LX-Z IP-LXM30Z-5 CEDI Module is a premium industrial Continuous Electrodeionization (CEDI) system that produces high-purity water (up to 18 MΩ·cm) without chemicals. Leveraging Siemens’ patented tech, it replaces traditional ion exchange systems, eliminating chemical regeneration and hazardous handling. CE-certified and made in China, it ensures stable performance for critical sectors like pharmaceuticals, microelectronics, and power generation, with minimal wastewater (90–95% recovery) and lower operational costs.
Key Applications
Ideal for industrial high-purity water needs:
• Pharmaceutical production (USP-purified water)
• Microelectronics/ semiconductor ultrapure water
• Power generation (boiler feed water)
• LNG, coal chemical, and solar energy processes
• Food, biotech, and steel industry water treatment
Specification Parameters
|
Parameter |
Value |
|
Design Flow Rate |
3.3–5.11 m³/hr (15.0–22.5 gpm) |
|
Minimum Flow Rate |
1.70 m³/hr (7.5 gpm) |
|
Recovery Rate |
90–95% |
|
Operating Temperature |
5–45°C (41–113°F) |
|
Inlet Pressure |
1.4–6.9 bar (20–100 psig) |
|
Product Resistivity |
>16 MΩ·cm (min flow >17 MΩ·cm) |
|
Shipping Weight |
132 kg (291 lbs) |
|
Operating Weight |
110 kg (243 lbs) |
|
Silica Removal |
90–99% (feed-dependent) |
Core Advantages
1. Chemical-Free Operation: Uses electricity to regenerate resins, no acids/alkalis.
2. Durability: Corrosion-resistant materials, leak-proof seals, 7-bar pressure tolerance.
3. Efficiency: Adaptive DC power, 90–95% recovery, reduces energy/footprint.
4. Scalability: Modular design integrates into new/existing systems.
FAQ
Q1: What’s the minimum order quantity?
A1: 1 pc, supporting small-batch trials.
Q2: How long is delivery?
A2: 5–8 working days with standard export packing.
Q3: Can it handle high silica feed water?
A3: Yes, removes 90–99% silica (feed <1.0 ppm).
After-Sales
Each Ionpure LX-Z IP-LXM30Z-5 CEDI Module undergoes pre-shipment testing (ISO 9001/14000). Technical support includes installation guidance and maintenance tips. Payment via T/T; monthly supply capacity hits 60,000 units for stable orders.
