詳細情報 |
|||
| 出荷の重量（kg）: | 52 | 寸法（width x height x深さとしてのcm）: | 30 x 61 x 29 |
|---|---|---|---|
| 最大水量 (m3/h): | 1.5 | 最低水量 (m3/h): | 0.5 |
| 典型的な設計された水生産（M3 /HR）: | 0.5-1.5 | 回復: | 93%まで |
| 電圧（VDC）: | 0〜150 | ぼんやり (NTU): | <1.0 |
| ハイライト: | EDI電気化ユニット、電気化RO EDI水処理、RO連続電子化システム | ||
製品の説明
The Veolia EDI Modules MK-3MiniH are compact, high-efficiency electrodeionization (EDI) systems engineered by Veolia Water Technologies, designed to produce consistent high-purity water for small to medium-scale industrial applications. As a specialized model in Veolia’s EDI lineup, these modules combine ion exchange resins, selective ion membranes, and low-voltage DC power to remove ions from pre-treated feed water (typically RO permeate), eliminating the need for chemical regeneration and reducing environmental impact. The Veolia EDI Modules MK-3MiniH stand out for their space-saving design, making them ideal for facilities with limited footprint while delivering reliable performance.
The core工艺 of Veolia EDI Modules MK-3MiniH involves electrochemical regeneration: DC power drives ions through selective membranes into a concentrate stream, while resins remain continuously regenerated—no acid or caustic chemicals required. This process ensures stable product water quality with minimal operational hassle, as it operates 24/7 without the downtime associated with traditional ion exchange systems.
Key Specifications of Veolia EDI Modules MK-3MiniH
|
Attribute |
Value |
|
Maximum Water Production |
1.5 m³/h |
|
Recovery Rate |
Up to 93% |
|
Product Water Resistivity |
15-18 MΩ·cm |
|
Operating Voltage |
0-300 V DC |
|
Operating Temperature Range |
5-45°C |
|
Feed Water Conductivity |
<50 μS/cm |
|
Dimensions (L×W×H) |
450×250×600 mm |
The Veolia EDI Modules MK-3MiniH offer distinct advantages: compact size saves installation space, chemical-free operation cuts safety risks and disposal costs, and high recovery rate minimizes water waste. They are widely used in pharmaceutical formulation, electronics manufacturing, laboratory water systems, and boiler feed water treatment. With Veolia’s global expertise in water technologies, the Veolia EDI Modules MK-3MiniH deliver a cost-effective, sustainable solution for businesses seeking reliable high-purity water without compromising on efficiency or environmental responsibility.
