DuPont AmberLite HPR650 H Cation Resin with 46.0 – 52.0% Water Retention Capacity and H⁺ ≥ 99% Ionic Conversion for Power Plant Condensate Polishing
商品の詳細:
| 起源の場所: | 中国 |
| ブランド名: | Dupont |
| 証明: | ISO9001 |
| モデル番号: | Dupont™Amberlite™HPR650 H |
| ドキュメント: | IER-AmberLite-HPR650-H-PDS-...en.pdf |
お支払配送条件:
| 最小注文数量: | 1pc |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | 標準輸出梱包 |
| 受渡し時間: | 5-8勤務日 |
| 支払条件: | T/T |
| 供給の能力: | 月額60000ユニット |
|
詳細情報 |
|||
| HPR650 H コポリマー: | スチレンジビニルベンゼン | HPR650 H マトリックス: | ゲル |
|---|---|---|---|
| HPR650 Hタイプ: | 強酸カチオン | HPR650 H官能基: | 硫酸 |
| HPR650 H 保水力: | 46.0 - 52.0％（h⁺form） | HPR650 H イオン変換: | H⁺≥99％ |
| HPR650H 用途: | 電力産業向けの混合ベッド脱灰のアプリケーション | ||
| ハイライト: | 46.0 – 52.0% water retention capacity Cation Resin,H⁺ ≥ 99% ionic conversion Ion Exchange Resin,650 ± 50 μm particle diameter AmberLite HPR650 H |
||
製品の説明
DuPont™ AmberLite™ HPR650 H is a high-quality, high-exchange capacity, and uniform particle size gel strong acid cation exchange resin. It is specifically designed for mixed beds in condensate polishing at nuclear and fossil fuel power plants, meeting the most demanding requirements for resin purity and water quality. This resin was formerly marketed and known as DOWEX MONOSPHERE™ 650C (H) ion exchange resin.
- Recommended Pairings:
- AmberLite™ HPR550 OH Ion Exchange Resin (gel)
- AmberLite™ HPR9000 OH Ion Exchange Resin (macroporous)
- Additional Options:
- AmberLite™ HPR550 Cl Ion Exchange Resin (gel)
- AmberLite™ HPR9000 SO₄ Ion Exchange Resin (macroporous)
- Mixed bed condensate polishing in PWR nuclear power plants
- Mixed bed condensate polishing in fossil fuel power plants
- Mixed bed polishing in industrial demineralization systems
AmberLite™ HPR650 H Ion Exchange Resin was previously sold as DOWEX MONOSPHERE™ 650C (H) Ion Exchange Resin.
| Physical Properties | |
|---|---|
| Copolymer | Styrene-divinylbenzene |
| Matrix | Gel |
| Type | Strong acid cation |
| Functional Group | Sulfonic acid |
| Physical Form | Dark amber, translucent, spherical beads |
| Chemical Properties | |
|---|---|
| Ionic Form as Shipped | H⁺ |
| Total Exchange Capacity | ≥ 2.0 eq/L (H⁺ form) |
| Water Retention Capacity | 46.0 - 52.0% (H⁺ form) |
| Ionic Conversion | H⁺ ≥ 99% |
| Particle Size | |
|---|---|
| Particle Diameter | 650 ± 50 μm |
| Uniformity Coefficient | ≤ 1.10 |
| < 300 μm | ≤ 0.5% |
| > 850 μm | ≤ 5.0% |
| For additional particle size information, please refer to the Particle Size Distribution Cross Reference Chart (Form No. 45-D00954-en). | |
| Purity (dry basis) | |
|---|---|
| Metals: |
|
| Stability | |
|---|---|
| Whole Uncracked Beads | ≥ 95% |
| Friability: |
|
| Swelling (Na⁺ -> H⁺) | 7% |
| Density | |
|---|---|
| Particle Density | 1.22 g/mL |
| Shipping Weight | 785 g/L |
Temperature Range (H⁺ form): 5 - 150°C (41 - 302°F)
pH Range (Stable): 0 - 14
For further details regarding recommended minimum bed depth, operating conditions, and regeneration procedures for mixed beds (Form No. 45-D01127-en) or separate beds (Form No. 45-D01131-en) in water treatment, please refer to our Technical Facts documents.
