DuPont AmberLite HPR4200 Cl Ion Exchange Resin for Industrial Water Demineralization with Whole Uncracked Beads ≥ 90% and Swelling 20%
商品の詳細:
| 起源の場所: | 中国 |
| ブランド名: | Dupont |
| 証明: | ISO9001 |
| モデル番号: | Dupont™Amberlite™HPR4200 CL |
| ドキュメント: | IER-AmberLite-HPR4200-Cl-PD...en.pdf |
お支払配送条件:
| 最小注文数量: | 1pc |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | 標準輸出梱包 |
| 受渡し時間: | 5-8勤務日 |
| 支払条件: | T/T |
| 供給の能力: | 月額60000ユニット |
|
詳細情報 |
|||
| HPR4200 CLの主な用途: | 工業用水の脱塩 | HPR4200 CL クラックのない全ビーズ: | 90％以上 |
|---|---|---|---|
| HPR4200 CL 膨潤（Cl⁻→OH⁻）: | 20％ | HPR4200 CL 粒子密度: | 1.07 g/ml |
| HPR4200 CL 警告: | 強い酸化剤（例、硝酸）は樹脂を分解したり、暴力反応を引き起こす可能性があります。使用する前に専門家に相談してください。 | HPR4200 CL の物理的形状: | 黄色の半透明の球状ビーズ |
| タイプ: | 強いベースアニオン、タイプI | ||
| ハイライト: | Whole Uncracked Beads Ion Exchange Resin,Swelling 20% AmberLite HPR4200 Cl,Particle Density 1.07 g/mL Water Treatment Resin |
||
製品の説明
DuPont™ AmberLite™ HPR4200 Cl Ion Exchange Resin for Industrial Water Demineralization
DuPont™ AmberLite™ HPR4200 Cl is a high-quality, uniform particle size, gel, Type I strong base anion exchange resin designed for industrial water demineralization applications. It is shipped in the chloride (Cl⁻) form.
Product Overview
This resin is engineered to deliver high operating capacity and low pressure drop, which contributes to reduced chemical consumption during regeneration and lower rinsing water requirements, offering cost-effective operation. Its balanced chemical and physical properties make it a versatile and high-performance choice for various water treatment systems.
Applications
- Demineralization
- Ideal for treating water with a high percentage of silica
- Effective for removing strong and weak acids and achieving low silica leakage
- Mixed bed polishing
Compatible System Designs
- Mixed beds
- Packed beds
- Layered beds
- Counter-current / hold-down systems
- Co-current systems
Recommended Resin Pairings
- For mixed beds:
- AmberLite™ HPR1200 H (gel)
- AmberLite™ HPR1300 H (gel)
- For layered beds:
- AmberLite™ HPR9500 (macroporous)
- AmberLite™ HPR9600 (macroporous)
Historical Reference
Previously sold as DOWEX MARATHON™ 4200 Cl Ion Exchange Resin.
Typical Properties
Physical Properties
| Property | Specification |
|---|---|
| Copolymer | Styrene-divinylbenzene |
| Matrix | Gel |
| Type | Strong base anion, Type I |
| Functional Group | Trimethylammonium |
| Physical Form | Yellow translucent spherical beads |
Chemical Properties
| Property | Specification |
|---|---|
| Ionic Form (as shipped) | Cl⁻ |
| Total Exchange Capacity | ≥ 1.30 eq/L (Cl⁻ form) |
| Water Retention Capacity | 49.0 - 55.0% (Cl⁻ form) |
Particle Size Distribution
| Parameter | Specification |
|---|---|
| Particle Diameter | 650 ± 50 μm |
| Uniformity Coefficient | ≤ 1.25 |
| < 300 μm | ≤ 0.3% |
| > 850 μm | ≤ 5.0% |
For additional particle size information, refer to Document No. 45-D00954-en.
Stability
- Whole Uncracked Beads: ≥ 90%
- Swelling (Cl⁻ -> OH⁻): 20%
Density
- Particle Density: 1.07 g/mL
- Shipping Weight: 670 g/L
Operating Conditions
- Temperature Range:
- OH⁻ form: 5 - 60°C (41 - 140°F) †
- Cl⁻ form: 5 - 100°C (41 - 212°F)
- pH Range:
- Service Cycle: 1 - 14
- Stable: 0 - 14
† Operating at elevated temperatures (e.g., >60-70°C) may impact resin life. Consult DuPont technical representatives for details.
Hydraulic Characteristics
- Backwash Expansion: Estimated bed expansion as a function of backwash flow rate and temperature is shown in Figure 1.
- Pressure Drop: Estimated pressure drop as a function of service flow rate and temperature is shown in Figure 2 (valid for clean water at service run start).
(Note: Refer to original document for graphical data.)
Safety & Compliance
Warning: Strong oxidizing agents (e.g., nitric acid) may degrade the resin or cause violent reactions. Consult experts before use.
Users should review safety data sheets (SDS) and ensure compliance with local regulations.
