DuPont™ AmberLite™ MB20 H/OH Mixed Bed Ion Exchange Resin – High Purity Deionization
商品の詳細:
| 起源の場所: | 中国 |
| ブランド名: | Dupont |
| 証明: | ISO9001 |
| モデル番号: | Dupont™Amberlite™MB20 H/OH |
| ドキュメント: | IER-AmberLite-MB20-H-OH-PDS...en.pdf |
お支払配送条件:
| 最小注文数量: | 1PC |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | 標準輸出梱包 |
| 受渡し時間: | 5-8勤務日 |
| 支払条件: | T/T |
| 供給の能力: | 月額60000ユニット |
|
詳細情報 |
|||
| 温度範囲: | 5〜60°C（41〜140°F） | Ph 範囲: | 0-14 |
|---|---|---|---|
| 処理水の導電率: | < 0.1μS/cm | 樹脂の外観: | 琥珀色のビーズ |
| 樹脂のpH: | 5.0～9.0 | 相対密度: | 1.080 – 1.200 |
| ハイライト: | DuPont AmberLite MB20 ion exchange resin,MB20 H/OH mixed bed resin,high purity deionization resin |
||
製品の説明
DuPont™ AmberLite™ MB20 H/OH is a high-purity, nuclear-grade mixed bed ion exchange resin consisting of a hydrogen-form strong acid cation exchanger and a hydroxide-form strong base anion exchanger. It is designed for critical demineralization applications requiring extremely low ionic leakage, including power generation, electronics, and pharmaceutical industries. The resin delivers excellent chemical and thermal stability, high operating capacity, and easy separation upon exhaustion. Formerly supplied as part of high-performance mixed bed systems.
High-purity water polishing (condensate polishing, nuclear power, supercritical boilers)
Electronics industry ultrapure water production
Pharmaceutical and laboratory demineralization
Mixed bed deionization after reverse osmosis (RO)
Note: This product is intended for use in mixed bed systems where separation of cation and anion resins is required for regeneration.
Mixed bed deionizers (separate or layered bed)
Packed bed mixed bed systems
Condensate polishing units (power plants)
Refillable cartridges and portable exchange deionization (PDI / IX) systems
| Property | Cation Resin | Anion Resin |
|---|---|---|
| Copolymer | Styrene-divinylbenzene | Styrene-divinylbenzene |
| Matrix | Gel | Gel |
| Type | Strong acid cation | Strong base anion, Type I |
| Functional Group | Sulfonic acid | Trimethylammonium |
| Physical Form | Dark amber translucent spherical beads | Light amber translucent spherical beads |
| Volume Ratio | 38 - 44% | 62 - 56% |
| Ionic Form as Shipped | H⁺ | OH⁻ |
| Particle Size (<300 μm) | ≤ 3.0% | |
| Shipping Weight | 710 g/L |
BV=500/TDS (meq/L) or kgr/ft³=187000/TDS (ppm CaCO₃)
- BV (Bed Volume): Liters of water (with TDS in meq/L) that can be treated per liter of resin.
- kgr/ft³: Grains per cubic foot of resin when TDS is expressed as ppm CaCO₃.
- Temperature Range: 5 - 60°C (41 - 140°F)
- pH Range: 0 - 14
- Treated Water Quality: Conductivity < 0.1 μS/cm, neutral pH
- Backwash Expansion Rates (Figs. 1a, 1b): Show bed expansion rates for cation and anion resins under different backwash flow rates and temperatures.
- Pressure Drop Characteristics (Fig. 2): Illustrate pressure drop variations under different service flow rates and temperatures (applicable to clean water and well-classified beds).
- Refer to the latest Safety Data Sheet (SDS) prior to use and ensure compliance with local regulations for operation and disposal.
- DuPont encourages users to evaluate processes and product applications from health, safety, and environmental perspectives.
